The UAC-8 uses high-end components such as the AKM AK5388 analog-to-digital converter and AKM AK4413 digital-to-analog converter. In addition, the UAC-8 performs 4-times upsampling during both analog-to-digital and digital-to-analog conversion. In other words, when the sampling frequency is set to 44.1kHz or 48kHz, the UAC-8 processes the signal at high resolution 176.4kHz or 192kHz.
For A/D conversion, this means less aliasing noise; for D/A conversion, this means increased clarity and fidelity.
In standalone mode, the UAC-8 can be used as an 8-channel mic preamp and analog-to-digital or digital-to-analog converter without being connected to a computer.
UAC-8 MixEfx is a free Macintosh and Windows compatible application designed specially by Zoom for the UAC-8. It provides a comprehensive onscreen mixer, with independent level, phase reversal, and panning control for each channel. UAC-8 MixEfx also allows you to freely route all inputs to all outputs and to create custom mixes. In addition, MixEfx features effects like reverb and echo, and complete mixes can be stored in three different memory slots, allowing instant recall.
The Zoom UAC-8 comes with a free download license for Sternberg’s Cubase LE music production software, providing not just the ability to capture incredible high-resolution / low-latency audio in every box, but to do spectacular things with it.
Take your recordings to a more professional level. Steinberg’s powerful and state-of-the-art audio software used by creators around the world now comes with every Zoom UAC-2 and UAC-8 purchase.
Features
18-in/20-out USB 3.0 SuperSpeed audio interface
Standalone mode allows use as an 8-channel mic preamp and A/D or D/A converter without connection to a computer
Support for recording and playback of up to 24-bit/192kHz high-resolution audio
Low latency audio streaming
8 combo balanced XLR/TRS analog input connectors accept both mic and line-level signal
High-performance mic preamps with up to +60dB of amplification
Hi-Z switches allow direct connection of electric guitar or bass
Independent gain controls and clip LEDs for each input
Switchable +48V phantom power
10 balanced TRS output jacks
Dual front-panel 1/4" headphone outputs with dedicated volume controls
S/PDIF IN/OUT: 2IN / 2OUT, up to 24-bit/192kHz
ADAT Optical IN/OUT: 2 IN / 2 OUT at 192/176.4kHz (S/MUX4 compatible), 4 IN/4 OUT at 96/88.2kHz (S/MUX compatible), 8 IN / 8 OUT at 48/44.1kHz
Word Clock in/out
Clock source indicator
MIDI in/out
Rack-mountable (1U space)

(930013011661)

SKU 930013011661
Barcode # 930013011661
Brand ZOOM
